FORGED TEE
Threaded Tee &Socket Weld Tee
Material : A182 F304/304L/316L/316Ti/321/904L,317L,347H,904L,S31803,S32750,N08825,N06625
Production Range : 1/8''-4''
Pressure: 3000LBS ,6000LBS, 9000LBS
Products
Elbow 90 Degree, Elbow 45 Degree, Tee, Cross, Union, Street Elbow, Coupling, Half Coupling, Reducing Coupling, Cap, Hex Head Bushing, Hex Head Plug, Square Head Plug, Round Head Plug, Bull Plug, Boss, Outlet, Hex Nipple, Swage Nipple
Dimension Specifications ASME 16.11, MSS SP-79, 83, 95, 97, BS 3799
Size 1/8″~4″ (DN6~DN100)
Forged Pipe Fittings ManufacturingStandards
ASME B16.11 – ForgedFittings, Socket – Welding and Threaded
MSS SP-43 –Wrought and Fabricated Butt-Welding Fittings for Low Pressure, CorrosionResistant Applications
MSS SP-95 – Swage (d) Nipples and Bull Plugs
BS3799 –Specification for Steel pipe fittings, screwed and Socket-welding for thepetroleum industry
Threaded Tee
Material : A182 F304/304L/316L/316Ti/321/904L,317L,347H,904L,S31803,S32750,N08825,N06625
Production Range : 1/8''-4''
Pressure: 3000LBS ,6000LBS, 9000LBS
Forged pipe fittings are made according to ASME B16.11, MSS-SP-79\83\95\97 and BS3799 standards. It is a connector in between nominal bore pipes. The fittings are made of carbon steel A105 A350 LF2 ,stainless steel SS304L SS316L,Alloy steel A182 F11,F22,F5,F9 material. The size available is from 1/8” to 4”
No
Type of Forged Pipe Fittings
Connection
1
Straight Coupling
Female x Female
2
90D / 45D Elbow
Female x Female
3
3 Way Tee
Female x Female x Female
4
3 Piece Union
Female x Female
5
End Cap
Female
6
90D / 45D Street Elbow
Female x Male
7
Hex Plug
Male
8
Hex Nipple
Male x Male
9
Hex Bush
Female x Male
10
Half Coupling
Female
ressure Class
Connection
Pipe Schedule
3000lb
Threaded
SCH 160
6000lb
Threaded
SCH XXS
3000lb
Socket Welding
SCH 80
6000lb
Socket Welding
SCH 160
