EQUAL TEE
Equal Tee
Material : Stainless steel , Alloy Steel , Carbon Steel ,Nickel Alloy,Copper Alloy,Titanium Alloy
Production Range : 1/2''-72'' (DN10~DN1800)
Wall Thickness : SCH5S- XXS
Standard: ASME B16.9, ASMEB16.28,DIN2615,DIN2037, EN10253-2, EN10253-4, ГОСТ 17375-80
JIS2312,JIS2313,GB12459 ,GB13401, SH3408,SH3409,MSS-SP-75,MSS-SP-43
|
|
|
Outside Diameter:Seamless Pipe Tee ( 1/2″～24″), ERW / Welded/ Fabricated Pipe Tee (1/2″～48″)
Types: Equal Tee , Reducing Tee
Wall Thickness: 3mm– 40mm / SCH5, SCH10, SCH20, SCH30, SCH40, STD, SCH80, XS, SCH60, SCH80,SCH120, SCH140, SCH160, XXS
Production Grades: Stainless Steel, Alloy Steel, Duplex, Nickel Alloys, Low temperature Steel, Carbon Steel,Copper Nickle
Manufacturing Standards – Pipe Tee
ASME: ANSIB16.9, ANSI B16.28, MSS-SP-43
DIN: DIN2605, DIN2615, DIN2616, DIN2617, DIN28011
EN: EN10253-1, EN10253-2
ASTM A403 – ASME SA403 – StandardSpecification for Wrought Austenitic Stainless Steel Piping Fittings
ASME B16.9 – Factory-MadeWrought Fittings Butt-welding
ASME B16.25 – Butt-welding Ends
ASME B16.28 – ‘Wrought Steel Short Radius Elbows and Butt-welding Returns’
MSSSP-43 – ‘Wroughtand Fabricated Butt-Welding Fittings for Low Pressure, Corrosion ResistantApplications
ГОСТ 17375-80,ГОСТ 30753-80, ГОСТ 17376-80, ГОСТ 17378-80, ГОСТ 17379-80, ГОСТ 17375-80,ТУ 1468-002-31049454-04
Pipe Tee Material Grades
Stainless Steel Tee; ASTMA403 WP Gr. 304, 304H, 309, 310, 316, 316L, 317L, 321, 347, 904L
Carbon Steel Tee: ASTMA 234 WPB , WPBW, WPHY 42, WPHY 46, WPHY 52, WPH 60, WPHY 65 & WPHY 70.
Low Temperature Carbon Steel Tee: ASTM A420 WPL3, A420 WPL6
AlloySteel Tee: ASTM/ ASME A/SA 234 Gr. WP 1, WP 5, WP 9, WP 11, WP 12, WP 22, WP 91
DuplexSteel Tee: ASTMA 815, ASME SA 815 UNS NO S31803, S32205. Material No. 1.4462
Nickel Alloy Tee: ASTM / ASME SB 336 UNS 2200 ( NICKEL 200 ), UNS 2201(NICKEL 201 ), UNS 4400 (MONEL 400 ), UNS 8020 ( ALLOY 20 / 20 CB 3, UNS 8825INCONEL (825), UNS 6600 (INCONEL 600 ), UNS 6601 ( INCONEL 601 ), UNS 6625(INCONEL 625), UNS 10276 ( HASTELLOY C 276 )
Packaging of Elbow
Wuxi Well Products are packed and labeled according to the regulations and customer's requests. Great care is taken to avoid any damage which might be caused during storage or transportation. In addition, clear labels are tagged on the outside of the packages for easy identification of the product I. D. and quality information.
1) Wuxi Well Standard
2) Customization
